90° Metric Female 24° Cone O-ring L.T.

PEHEL Hydraulic Model: P20491W-PK

QTY:

Hydraulic pipe fittings DKOL elbow Metric hose fitting

  • You May Also Like

  • PART NO. THREAD E HOSE BORE DIMENSIONS
    DN DASH A B C H S1
    20491-14-04WPK AST M14X1.5 6 04 51 29 1.1 29 17
    20491-16-05WPK AST M16X1.5 8 05 58 34 0.7 33 19
    20491-18-06WPK AST M18X1.5 10 06 61 32.5 1.6 34 22
    20491-22-08WPK AST M22X1.5 12 08 75 41 1.4 42 27
    20491-26-08WPK AST M18X1.5 12 08 74 37 2 43 32
    20491-26-10WPK AST M18X1.5 16 10 83 44.2 2 49 32
