Home / / Union - One Piece Fitting / 90° JIC Female 74° Cone Seat

90° JIC Female 74° Cone Seat

PEHEL Hydraulic Model: P26791-PK

QTY:

JIC Female 74 degree Cone Seat 90 degree elbow JIC Hydraulic Fittings hydraulic fittings for excavator

  • You May Also Like

  • PART NO. E (THREAD E) HOSE BORE (DN) HOSE BORE (DASH) DIMENSIONS (A) DIMENSIONS (B) DIMENSIONS (H) DIMENSIONS (S1) Per hundred weight Weight per case
    26791-06-06PK 9/16"X18 10 6 61 39 39 19 10.6 80
    26791-08-06PK 3/4"X16 10 6 61 39 40 24 8.8 80
    26791-08-08PK 3/4"X16 12 8 72.5 44 47 24 18.2 0
    26791-10-10PK 7/8"X14 16 10 93 55.9 52.5 27 26.5 40
    26791-12-12PK 1.1/16"X12 20 12 103.5 63.9 63 32 35.8 30
    26791-16-16PK 1.5/16"X12 25 16 122 77 70 38 67.1 20
    26791-20-20PK 1.5/8"X12 32 20 137.8 90.8 84.5 50 116.8 15
    26791-24-24PK 1.7/8"X12 40 24 148 109.6 101.5 60 168.2 10
    26791-32-32PK 2.1/2"X12 50 32 178 130.8 122.5 73 4
    26791-06-04PK 9/16"X18 6 4 52.5 32.9 33 19 6.9 100
    26791-10-08PK 7/8"X14 12 8 72.5 44 48 27 19.3 30
