PART NO. FLANGE SIZE DIMENSIONS BOLT MPa A B C D E FS-08 1/2" 56.3 49.2 40.5 9 18.2 M8X30 42 FS-12 3/4" 71.4 61.8 50.8 11 23.8 M10X35 FS-16 1" 81 71.4 57.2 13 27.8 M12X45 FS-20 1.1/4" 95.3 79.2 66.7 15 31.8 M14X50 FS-24 1.1/2" 112.8 96.8 79.4 17 36.6 M16X55 FS-32 2" 133.4 115.6 96.8 21 44.4 M20X70 NOTE:1.Bolt should be ordered anther.
SAE Split Flange Clamps 6000PSI
PEHEL Hydraulic Model: PFS
QTY:
- SAE Flang H.T. Description:the marerial is 45 carbon steel. PFS is our 6000PSI hydraulic flange part no .
