SAE thread port and mating stud end

SAE thread port and mating stud end

PEHEL Hydraulic Model: SAE thread port and mating stud end

QTY:

  • SAE thread port and mating stud end Specification
  • You May Also Like
  • d1
    THREAD    		 d2 d4
    (min)    		 d5
    (±0.05)    		 L1
    (±0.2)    		 L2
    (min)     		L3 L4
    (min)    		 Z
    (±1°)
    5/16”X24 17 11 9.15 2.1 12 1.6 10 12°
    3/8”X24 19 13 10.75 12 10
    7/16”X20 21 15 12.45 2.6 14 11.5
    1/2”X20 23 16 14.05 14 11.5
    9/16”X18 25 18 15.70 2.7 15.5 12.7
    3/4”X16 30 22 20.65 17.5 2.4 14.3 15°
    7/8”X14 34 26 24 20 16.7
    1.1/16”X12 41 32 29.2 3.5 23 19
    1.3/16”X12 45 35 32.4
    1.5/16”X12 49 38 35.55 3.2
    1.5/8”X12 58 48 43.55
    1.7/8”X12 65 54 49.9
    2.1/2”X12 88 70 65.75
