PART NO.
THREAD
O-RING
DIMENSIONS
E、F
E
A
B
S1
S2
2E9-12
M12X1.25
8X1.9
20.5
8
12
17
2E9-14
M14X1.5
10X2
22.5
8.5
14
19
2E9-16
M16X1.5
11X1.9
25
8.5
16
22
2E9-18
M18X1.5
13X2
26
8.5
19
24
2E9-22
M22X1.5
16.1X2.4
29.5
10
22
27
2E9-27
M27X1.5
20.1X2.4
32.5
10
27
32
2E9-30
M30X1.5
24.1X2.4
35.5
11
30
36
2E9-36
M36X2
30X3.1
42
13
36
41
2E9-39
M39X2
32X3.1
47.5
13
41
46
2E9-42
M42X2
35X3.1
49.5
15
41
50
2E9-45
M45X2
38X3.1
52.5
15
46
55
2E9-52
M52X2
40X3.1
56
17
50
60
90° Elbow Metric Male O-ring
PEHEL Hydraulic Model: P2E9
