THREAD DIMENSIONS PART NO. O-RING MPa E,F G TUBE O.D. I1,I2 L1,L2 L3 S1 S2,S3 S4 ACCH-12-12-10OG M12X1.5 M10X1 6 O08.1X1.6 13 28 26.5 11 14 14 31.5 L ACCH-14-14-12OG M14X1.5 M12X1.5 8 O09.3X2.4 15.5 30.5 32.5 14 17 17 ACCH-16-16-14OG M16X1.5 M14X1.5 10 O11.3X2.4 17.5 32.5 34 16 19 19 ACCH-18-18-16OG M18X1.5 M16X1.5 12 O13.3X2.4 19 34 36 19 22 22 ACCH-22-22-18OG M22X1.5 M18X1.5 15 O15.3X2.4 22 37 39.5 22 27 24 ACCH-26-26-22OG M26X1.5 M22X1.5 18 O19.3X2.4 25.5 42 43.5 27 32 27 ACCH-30-30-27OG M30X2 M27X2 22 O23.5X3.0 29.5 45.8 50 30 36 32 16 L ACCH-36-36-33OG M36X2 M33X2 28 O29.5X3.0 33.3 49.8 54 36 41 41 ADDH-14-14-12OG M14X1.5 M12X1.5 6 O09.3X2.4 17.5 32.5 32.5 14 17 17 63 S ADDH-16-16-14OG M16X1.5 M14X1.5 8 O11.3X2.4 18.5 33.7 33.5 16 19 19 ADDH-18-18-16OG M18X1.5 M16X1.5 10 O13.3X2.4 19.5 36 36 19 22 22 ADDH-20-20-18OG M20X1.5 M18X1.5 12 O15.3X2.4 19.5 36 37 19 24 24 ADDH-24-24-22OG M24X1.5 M22X1.5 16 O19.3X2.4 24 42 41 24 30 27 ADDH-30-30-27OG M30X2 M27X2 20 O23.5X3.0 28.3 49.8 50 30 36 32 40 S ADDH-36-36-33OG M36X2 M33X2 25 O29.5X3.0 32.8 56.8 54 36 46 41 ADDH-42OG M42X2 M42X2 30 O38.5X3.0 36.2 62.7 57.2 41 50 50
PACCH-OG PADDH-OG/PACCH-OG/RN PADDH-OG/RN
PEHEL Hydraulic Model: PACCH-OG PADDH-OG/PACCH-OG/RN PADDH-OG/RN
