PART NO.THREAD TUBE O.D. DIMENSIONS
MPaE F D1 B l1 L1 S1 S2 1CM-12-10WD M12X1.5 M10X1 6 8 8.5 23 14 14 31.5 L 1CM-14-12WD M14X1.5 M12X1.5 8 12 10 25 17 17 1CM-16-12WD M16X1.5 M12X1.5 10 12 11 25 17 19 1CM-16-14WD M16X1.5 M14X1.5 10 12 11 26 19 19 1CM-16-18WD M16X1.5 M18X1.5 10 12 12.5 27 24 19 1CM-18-16WD M18X1.5 M16X1.5 12 12 12.5 27 22 22 1CM-18WD M18X1.5 M18X1.5 12 12 12.5 27 24 22 1CM-18-22WD M18X1.5 M22X1.5 12 14 14 29 27 22 1CM-22-18WD M22X1.5 M18X1.5 15 12 13.5 29 24 27 1CM-22WD M22X1.5 M22X1.5 15 14 15 30 27 27 1CM-26-22WD M26X1.5 M22X1.5 18 14 14.5 31 27 32 1CM-30-26WD M30X2 M26X1.5 22 16 16.5 33 32 36 16 L 1CM-30-27WD M30X2 M27X1.5 22 16 16.5 33 32 36 1CM-36-33WD M36X2 M33X2 28 18 17.5 34 41 41 1CM-45-42WD M45X2 M42X2 35 20 17.5 39 50 50 1CM-52-48WD M52X2 M48X2 42 22 19 42 55 60 1DM-14-12WD M14X1.5 M12X1.5 6 12 13 28 17 17 63 S 1DM-16-14WD M16X1.5 M14X1.5 8 12 15 30 19 19 1DM-18-16WD M18X1.5 M16X1.5 10 12 15 31 22 22 1DM-20-18WD M20X1.5 M18X1.5 12 12 17 33 24 24 1DM-22-20WD M22X1.5 M20X1.5 14 14 19 37 27 27 1DM-24-22WD M24X1.5 M22X1.5 16 14 18.5 37 27 30 40 S 1DM-30-27WD M30X2 M27X2 20 16 20.5 42 32 36 1DM-36-33WD M36X2 M33X2 25 18 23 47 41 46 1DM-42WD M42X2 M42X2 30 20 23.5 50 50 50 1DM-52-48WD M52X2 M48X2 38 22 26 57 55 60 31.5 S Note:In case if you are interested to order the adapter in complete set with cutting ring and nut ,it is necessary to insert suffix "RN" after our part no.,for example 1DM-20-18WD/RN.
Metric Thread with Captive Seal
PEHEL Hydraulic Model: 1CM-1DM-WD
QTY:
