PART NO. THREAD TUBE O.D. DIMENSIONS MPa E F D1 B l1 L1 S1 S2 1CJ-14-04 M14x1.5 7/16"X20 8 14 8 23 15 17 31.5 L 1CJ-14-06 M14x1.5 9/16"X18 8 14.1 8 23 15 17 1CJ-16-06 M16x1.5 9/16"X18 10 14.1 9 24 17 19 1CJ-18-06 M18x1.5 9/16"X18 12 14.1 10 25 19 22 1CJ-18-08 M18x1.5 3/4"X16 12 16.7 10 25 22 22 1CJ-22-08 M22x1.5 3/4"X16 15 16.7 10.8 26 24 27 1CJ-22-10 M22x1.5 7/8"X14 15 19.3 11 26 24 27 1CJ-26-10 M26X1.5 7/8"X14 18 19.3 11.5 28 27 32 1CJ-26-12 M26X1.5 1.1/16"X12 18 21.9 11.6 28 30 32 1CJ-30-12 M30x2 1.1/16"X12 22 21.9 13.5 30 32 36 16 L 1CJ-36-16 M36x2 1.5/16"X12 28 23.1 14.5 31 38 41 1CJ-45-20 M45X2 1.5/8"X12 35 24.3 14.5 36 46 50 1CJ-52-20 M52X2 1.5/8"X12 42 24.3 16 39 55 60 1CJ-52-24 M52X2 1.7/8"X12 42 27.5 16 39 55 60 1DJ-16-04 M16x1.5 7/16"X20 8 14 13 28 17 19
63 S1DJ-16-06 M16x1.5 9/16"X18 8 14.1 12.9 28 17 34 1DJ-18-04 M18x1.5 7/16"X20 10 14 12.5 29 19 22 1DJ-18-06 M18x1.5 9/16"X18 10 14.1 12.5 29 19 22 1DJ-20-06 M20x1.5 9/16"X18 12 14.1 14.5 31 22 24 1DJ-20-08 M20x1.5 3/4"X16 12 16.7 14.3 31 22 24 1DJ-22-08 M22x1.5 3/4"X16 14 16.7 16 34 24 27 1DJ-24-08 M24x1.5 3/4"X16 16 16.7 15.5 34 27 30 40 S 1DJ-30-12 M30x2 1.1/16"X12 20 21.9 17.5 39 32 36 1DJ-36-12 M36x2 1.1/16X12 25 21.9 19 43 38 46 1DJ-36-16 M36x2 1.5/16X12 25 23.1 19 43 38 46 1DJ-42-20 M42x2 1.5/8"X12 30 24.3 20.5 47 46 50 1DJ-52-24 M52X2 1.7/8"X12 38 27.5 23 54 55 60 31.5 S Note:In case if you are interested to order the adapter in complete set with cutting ring
JIC 74 Cone Sealing
PEHEL Hydraulic Model: 1CJ-1DJ
QTY:
