Weld Fittings

PEHEL Hydraulic Model: P1CW

QTY:

  • You May Also Like

  • PART NO.

    THREAD TUBE O.D. DIMENSIONS
    E D1 D2 D L S
    P1CW-12-06 M12X1.5 6 6 10 21 12
    P1CW-14-08 M14X1.5 8 8 12 23 14
    P1CW-16-10 M16X1.5 10 10 14 24 17
    P1CW-18-12 M18X1.5 12 12 16 25 19
    P1CW-22-15 M22X1.5 15 15 19 28 24
    P1CW-26-18 M26X1.5 18 18 22 29 27
    P1CW-26-22 M26X1.5 18 22 27 31 27
    P1CW-30-22 M30X2 22 22 27 33 32
    P1CW-30-25 M30X2 22 25 31 33 32
    P1CW-36-28 M36X2 28 28 32 36 38
    P1CW-45-35 M45X2 35 35 40 39 46
    P1CW-52-42 M52X2 42 42 46 43 55
