PART NO.
THREAD TUBE O.D. DIMENSIONS E F D1 D2 A B S1 L P6C -14 M14X1.5 M14X1.5 8 8 13 34 19 53 -16 M16X1.5 M16X1.5 10 10 13.5 35 22 56.5 -18 M18X1.5 M18X1.5 12 12 13.5 36 24 57.5 -22 M22X1.5 M22X1.5 15 15 13.5 38 27 61.5 -26 M26X1.5 M26X1.5 18 18 14 40 32 65 -30 M30X2 M30X2 22 22 18 42 36 71 -36 M36X2 M36X2 28 28 18 43 41 74.5 -45 M45X2 M45X2 35 35 19 47 50 81 -52 M52X2 M52X2 42 42 19 47 60 81
Straight Bulkhead Fittings
PEHEL Hydraulic Model: P6C
QTY:
