PART NO.
THREAD TUBE O.D. DIMENSIONS E F D A B L S1 P1CT-14-04SP M14X1.5 R1/4"X19 8 13 14.5 34 17 P1CT-14-06SP M14X1.5 R3/8"X19 8 13 15 34 19 P1CT-16-04SP M16X1.5 R1/4"X19 10 13.5 14.5 34 17 P1CT-16-06SP M16X1.5 R3/8"X19 10 13.5 15 34 19 P1CT-16-08SP M16X1.5 R1/2"X14 10 13.5 20 42 22 P1CT-16-12SP M16X1.5 R3/4"X14 10 13.5 20 44 30 P1CT-18-04SP M18X1.5 R1/4"X19 12 13.5 14.5 34 19 P1CT-18-06SP M18X1.5 R3/8"X19 12 13.5 15 34 19 P1CT-18-08SP M18X1.5 R1/2"X14 12 13.5 20 41 22 P1CT-22-08SP M22X1.5 R1/2"X14 15 13.5 20 41 24 P1CT-26-12SP M26X1.5 R3/4"X14 18 14 20 44 30 P1CT-30-12SP M30X2 R3/4"X14 22 18 20 49 32 P1CT-42-16SP M42X2 R1"X11 32 19 25.5 58 46 P1CT-42-20SP M42X2 R1.1/4"X11 32 19 26.5 59 46 P1CT-45-16SP M45X2 R1"X11 35 19 25.5 58 46 P1CT-45-20SP M45X2 R1.1/4"X11 35 19 26.5 59 46 P1CT-52-20SP M52X2 R1.1/4"X11 42 19 26.5 61 55 P1CT-52-24SP M52X2 R1.1/2"X11 42 19 26.5 61 55
