90º JIS Metric Female 60º Cone Seat

PEHEL Hydraulic Model: P28691

QTY:

28691 Japanese Metric 90° Elbow Male Fittings, 60° Cone Seat

  • You May Also Like

  • PART NO. THREAD E HOSE BORE DIMENSIONS
    DN DASH C S1 S2 H Per hundred weight
    Weight per case
    28691-14-04 M14X1.5 6 4 10.5 19 19 38 6.3 200
    28691-14-06 M14X1.5 10 6 10.5 19 19 43.3 9.3 150
    28691-16-05 M16X1.5 8 5 9.3 22 22 44 9.3 150
    28691-18-06 M18X1.5 10 6 11.5 24 24 46.3 11.6 100
    28691-22-08 M22X1.5 12 8 14 27 27 52.5 17.4 70
    28691-24-10 M24X1.5 16 10 15.1 32 32 59 27.8 60-80
    28691-30-12 M30X1.5 20 12 18.3 36 36 68.5 40.3 50
    28691-33-16 M33X1.5 25 16 21.3 41 41 76 71 30
    28691-36-20 M36X1.5 32 20 20 46 46 88 124.1 15-20
    28691-42-24 M42X1.5 40 24 18.8 55 55 103 10
