JIC Female 74º Cone Seat Double Hexagon

PEHEL Hydraulic Model: P26711D

QTY:

American Standard Jic Female Swivel Hydraulic Hose Fitting 26711

  • 26711D: double hexgon JIC 74 degree cone fitting.

  • You May Also Like

  • PART NO. THREAD E HOSE BORE DIMENSIONS
    DN DASH C S2 H Per hundred weight Weight per case
    P26711D-04-04 7/16"x20 6 4 9 15 15 3.5 300
    P26711D-05-04 1/2"x20 6 4 9.5 17 17 4.4 300
    P26711D-06-06 9/16"x18 10 6 10.5 19 19 5.1 250
    P26711D-08-06 3/4"x16 10 6 11 24 24 9 200
    P26711D-08-08 3/4"x16 12 8 11 24 24 9 150
    P26711D-08-10 3/4"x16 16 10 11 24 24 250
    P26711D-10-08 7/8"x14 12 8 14 27 27 11.7 120
    P26711D-12-12 1.1/16"x12 20 12 15 32 32 18.6 100
    P26711D-16-12 1.5/16"x12 20 12 16 41 41 29.5 80
    P26711D-16-16 1.5/16"x12 25 16 16 41 41 33.3 70
    P26711D-20-20 1.7/16"x12 32 20 17 50 50 55.3 50
