PART NO. THREAD DIMENSIONS E F A B S1 1JT4-04-02SP 7/16"X20 R1/8"X28 21.5 17 11 1JT4-04SP 7/16"X20 R1/4"X19 22.3 21 14 1JT4-04-06SP 7/16"X20 R3/8"X19 22.8 23 16 1JT4-04-08SP 7/16"X20 R1/2"X14 24.5 29.5 22 1JT4-05-02SP 1/2"X20 R1/8"X28 21.5 17.5 14 1JT4-05-04SP 1/2"X20 R1/4"X19 22.3 21 14 1JT4-05-06SP 1/2"X20 R3/8"X19 22.8 23 16 1JT4-06-02SP 9/16"X18 R1/8"X28 22.8 18.2 14 1JT4-06-04SP 9/16"X18 R1/4"X19 22.8 21 14 1JT4-06SP 9/16"X18 R3/8"X19 22.5 23 16 1JT4-06-08SP 9/16"X18 R1/2"X14 25 29.5 22 1JT4-08-04SP 3/4"X16 R1/4"X19 26.8 22 19 1JT4-08-06SP 3/4"X16 R3/8"X19 26.8 24 19 1JT4-08SP 3/4"X16 R1/2"X14 28 29.5 22 1JT4-08-12SP 3/4"X16 R3/4"X14 29 30.5 27 1JT4-10-06SP 7/8"X14 R3/8"X19 31 25 22 1JT4-10-08SP 7/8"X14 R1/2"X14 31 29.5 22 1JT4-10-12SP 7/8"X14 R3/4"X14 32 30.5 27 1JT4-12-08SP 1.1/16"X12 R1/2"X14 35.5 30 27 1JT4-12SP 1.1/16"X12 R3/4"X14 35.5 30.5 27 1JT4-12-16SP 1.1/16"X12 R1"X11 37.5 38 33 1JT4-16-12SP 1.5/16"X12 R3/4"X14 38.5 32.5 33 1JT4-16SP 1.5/16"X12 R1"X11 40 40 33 1JT4-16-20SP 1.5/16"X12 R1.1/4"X11 42 43 41 1JT4-20-16SP 1.5/8"X12 R1"X11 43 42 41 1JT4-20SP 1.5/8"X12 R1.1/4"X11 43 43 41 1JT4-20-24SP 1.5/8"X12 R1.1/2"X11 46 47.5 48 1JT4-24-20SP 1.7/8"X12 R1.1/4"X11 49 45.5 48 1JT4-24SP 1.7/8"X12 R1.1/2"X11 49 47.5 48 1JT4-32SP 2.1/2"X12 R2"X11 58 50 63
45° ELBOW JIC MALE 74° CONE / BSPT MALE
PEHEL Hydraulic Model: P1JT4-SP
QTY:
