PART NO. THREAD O-RING DIMENSIONS E F F A B S1 S2 1JO9-04-03OG 7/16"X20 3/8"X24 O903 24.5 28 11 14 1JO9-04OG 7/16"X20 7/16"X20 O904 24.5 28.2 11 17 1JO9-04-05OG 7/16"X20 1/2"X20 O905 26.6 29.9 14 17 1JO9-04-06OG 7/16""X20 9/16"X18 o906 26.6 31.8 14 19 1JO9-05-04OG 1/2"x20 7/16"X20 O904 26.6 30 14 17 1JO9-05OG 1/2"x20 1/2"x20 o905 26.6 29 14 17 1JO9-05-06OG 1/2"x20 9/16"X18 O906 26.6 31.8 14 19 1JO9-06-04OG 9/16"x18 7/16"X20 O904 26.9 32 14 17 1JO9-06-05OG 9/16"X18 1/2x20 O905 26.9 29.9 14 17 1JO9-06OG 9/16"X18 9/16"X18 o906 26.9 31.8 14 19 1JO9-06-08OG 9/16"X18 3/4X16 O908 30 36.8 19 24 1JO9-08-04OG 3/4"X16 7/16"X20 O904 32 33 19 17 1JO9-08-06OG 3/4”X16 9/16X18 O906 33 33.5 19 19 1JO9-08OG 3/4"X16 3/4"X16 O908 33 36.8 19 24 1JO9-08-10OG 3/4X16 7/8""X14 O910 34.8 44 22 27 1JO9-08-12OG 3/4"×16 1.1/16"X12 O912 37.9 51 27 32 1JO9-10-08OG 7/8"X14 3/4"×16 o908 38 40 22 24 1JO9-10OG 7/8"X14 7/8"X14 o910 37.8 44 22 27 1JO9-10-12OG 7/8"X14 1.1/16"X12 O912 41 51 27 32 1JO9-12-08OG 1.1/16"X12 3/4"X16 o908 45 55 27 24 1JO9-12-10OG 1.1/16"X12 7/8"X14 O910 44.2 58 27 27 1JO9-12OG 1.1/16"X12 1.1/16"X12 O912 44.2 51 27 32 1JO9-12-16OG 1.1/16"×12 1.5/16"X12 O916 47.8 54.5 33 41 1JO9-14OG 1.3/16X12 1.3/16"X12 O914 47.5 53 30 36 1JO9-14-16OG 1.3/16X12 1.5/16"×12 O916 45.5 54.5 33 41 1JO9-16-12OG 1.5/16"X12 1.1/16""X12 O912 48.8 54.5 33 32 1JO9-16-14OG 1.5/16X12 1.3/16""X12 O914 49 56 33 36 1JO9-16OG 1.5/16X12 1.5/16"X12 O916 48.8 54.5 33 41 1JO9-16-20OG 1.5/16"X12 1.5/8""X12 O920 53.8 59 41 50 1JO9-20-16OG 1.5/8"X12 1.5/16"X12 O916 55.5 59.5 41 41 1JO9-20OG 1.5/8""X12 1.5/8""X12 O920 55.3 59 41 50 1JO9-20-24OG 1.5/8""X12 1.7/8"X12 O924 59.4 63 48 55 1JO9-24OG 1.718"X12 1.7/8""X12 O924 62.5 63 48 55 1JO9-32OG 2.1/2""X12 2.1/2"X12 O932 80 76 63 70
90° ELBOW JIC MALE 74° CONE
PEHEL Hydraulic Model: P1JO9-OG
QTY:
