THREAD DIMENSIONS PART NO. E F A B S1 1JN4-02 5/16"X24 Z1/8"X27 18 17 11 1JN4-03-02 3/8"X24 Z1/8"X27 19 17 11 1JN4-04-02 7/16"X20 Z1/8"X27 21.5 17 11 1JN4-04 7/16"X20 Z1/4"X18 22.3 21 14 1JN4-04-06 7/16"X20 Z3/8"X18 23 24.5 19 1JN4-04-08 7/16"X20 Z1/2"X14 24.5 29.5 22 1JN4-05-02 1/2"X20 Z1/8"X27 22.3 18 14 1JN4-05-04 1/2"X20 Z1/4"X18 22.3 21 14 1JN4-06-02 9/16"X18 Z1/8"X27 22.8 17.3 14 1JN4-06-04 9/16"X18 Z1/4"X18 22.8 21 14 1JN4-06 9/16"X18 Z3/8"X18 24 24 19 1JN4-06-08 9/16"X18 Z1/2"X14 25 29.5 22 1JN4-08-04 3/4"X16 Z1/4"X18 26.8 22 19 1JN4-08-06 3/4"X16 Z3/8"X18 26.8 24 19 1JN4-08 3/4"X16 Z1/2"X14 28 29.5 22 1JN4-08-12 3/4"X16 Z3/4"X14 29 35 27 1JN4-10-08 7/8"X14 Z1/2"X14 31 29.5 22 1JN4-10-12 7/8"X14 Z3/4"X14 32 35 27 1JN4-12-08 1.1/16"X12 Z1/2"X14 35.5 31 27 1JN4-12 1.1/16"X12 Z3/4"X14 35.5 35 27 1JN4-12-16 1.1/16"X12 Z1"X11.5 37.5 39 33 1JN4-14-12 1.3/16"X12 Z3/4"X14 37 35.5 30 1JN4-16-12 1.5/16"X12 Z3/4"X14 38.5 36.5 33 1JN4-16 1.5/16"X12 Z1"X11.5 38.5 39 33 1JN4-16-20 1.5/16"X12 Z1.1/4"X11.5 42 42.5 41 1JN4-20-16 1.5/8"X12 Z1"X11.5 43 42.5 41 1JN4-20 1.5/8"X12 Z1.1/4"X11.5 43 42 41 1JN4-20-24 1.5/8"X12 Z1.1/2"X11.5 46 45 48 1JN4-24 1.7/8"X12 Z1.1/2"X11.5 49 45 48 1JN4-32 2.1/2"X12 Z2"X11.5 58 50 63
45° ELBOW JIC MALE 74° CONE / NPT MALE
PEHEL Hydraulic Model: P1JN4
QTY:
