PART NO. THREAD O-RING DIMENSIONS E F F A B L S1 1JH-04-10 7/16"X20 M10X1 O08.1X1.6 14 8.5 28.5 14 1JH-04-12 7/16"X20 M12X1.5 O09.3X2.4 14 11 31 17 1JH-04-14 7/16"X20 M14X1.5 O11.3X2.4 14 11 31 19 1JH-05-10 1/2"X20 M10X1 O08.1X1.6 14 8.5 29 14 1JH-05-12 1/2"X20 M12X1.5 O09.3X2.4 14 11 31 17 1JH-05-14 1/2"X20 M14X1.5 O11.3X2.4 14 11 33 19 1JH-06-14 9/16"X18 M14X1.5 O11.3X2.4 14.1 11 31 19 1JH-06-16 9/16"X18 M16X1.5 O13.3X2.4 14.1 11.5 33.5 22 1JH-06-18 9/16"X18 M18X1.5 O15.3X2.4 14.1 12.5 34.5 24 1JH-08-14 3/4"X16 M14X1.5 O11.3X2.4 16.7 11 38 22 1JH-08-16 3/4"X16 M16X1.5 O13.3X2.4 16.7 11.5 36 22 1JH-08-18 3/4"X16 M18X1.5 O15.3X2.4 16.7 12.5 37 24 1JH-08-22 3/4"X16 M22X1.5 O19.3X2.4 16.7 13 39.5 27 1JH-10-16 7/8"X14 M16X1.5 O13.3X2.4 19.3 11.5 41 24 1JH-10-18 7/8"X14 M18X1.5 O15.3X2.4 19.3 12.5 40 24 1JH-10-22 7/8"X14 M22X1.5 O19.3X2.4 19.3 13 42 27 1JH-12-22 1.1/16"X12 M22X1.5 O19.3X2.4 21.9 13 47.5 30 1JH-12-27 1.1/16"X12 M27X2 O23.5X3.0 21.9 16 51.5 32 1JH-16-27 1.5/16"X12 M27X2 O23.5X3.0 23.1 16 52.5 36 1JH-16-33 1.5/16"X12 M33X2 O29.5X3.0 23.1 16 52 41 1JH-20-42 1.5/8"X12 M42X2 O38.5X3.0 24.3 16 58 50 1JH-24-48 1.7/8"X12 M48X2 O44.5X3.0 27.5 17.5 63 55
JIC MALE 74° CONE
PEHEL Hydraulic Model: P1JH
QTY:
