Metric Male 60 SEAT/BSPT Male

Metric Male 60 SEAT/BSPT Male

PEHEL Hydraulic Model: 1MT-SP

QTY:

  • Metric Male 60 SEAT/BSPT Male Specification
  • You May Also Like
  • PART NO. THREAD DIMENSIONS
    E F A B L S1
    1MT-10-02SP M10X1 R1/8"X28 8 10 25 14
    1MT-12-02SP M12X1.5 R1/8"X28 10 10 27 17
    1MT-14-04SP M14X1.5 R1/4"X19 11 14.5 32.5 19
    1MT-16-06SP M16X1.5 R3/8"X19 11 15 35 22
    1MT-18-06SP M18X1.5 R3/8"X19 12 15 36 24
    1MT-22-08SP M22X1.5 R1/2"X14 14 20 45 27
    1MT-24-08SP M24X1.5 R1/2"X14 14 20 45 30
    1MT-26-08SP M26X1.5 R1/2"X14 16 20 48 32
    1MT-27-08SP M27X1.5 R1/2"X14 16 20 48 32
    1MT-30-12SP M30X1.5 R3/4"X14 18 20 50 36
    1MT-38-16SP M38X2 R1"X11 20 25.5 59.5 46
    1MT-45-20SP M45X2 R1.1/4"X11 20 26.5 62.5 55
    1MT-52-24SP M52X2 R1.1/2"X11 20 26.5 62.5 60
