Metric Female 60 Cone Seat

PEHEL Hydraulic Model: DK

QTY:

Japanese Hydraulic Fittings

  • You May Also Like

  • PART NO. THREAD DIMENSIONS
    E F G A,B,C S1 S2,S3,S4
    DK-14 M14X1.5 M14X1.5 M14X1.5 10.5 11 19
    DK-16 M16X1.5 M16X1.5 M16X1.5 9.3 14 22
    DK-18 M18X1.5 M18X1.5 M18X1.5 11.5 16 24
    DK-22 M22X1.5 M22X1.5 M22X1.5 14 19 27
    DK-24 M24X1.5 M24X1.5 M24X1.5 15.1 22 32
    DK-30 M30X1.5 M30X1.5 M30X1.5 18.3 27 36
    DK-33 M33X1.5 M33X1.5 M33X1.5 21.3 30 41
    DK-36 M36X1.5 M36X1.5 M36X1.5 20 33 46
    DK-42 M42X1.5 M42X1.5 M42X1.5 18.8 36 50
