PART NO. FLANGE SIZE DIMENSIONS with bolt MPa A B d h M N 3000PSI FL-08P 1/2" 54 45.6 9 6.2 38.1 17.5 M8X25
34.5FL-12P 3/4" 65 51.8 11 6.2 47.6 22.2 M10X30 FL-16P 1" 70 58.4 11 7.5 52.4 26.2 M10X30 FL-20P 1.1/4" 79 72.6 11 7.5 58.7 30.2 M10X30 27.6 FL-24P 1.1/2" 94 82.2 13.5 7.5 69.9 35.7 M12X35 20.7 FL-32P 2" 102 96.4 13.5 9 77.8 42.9 M12X35 6000PSI FS-08P 1/2" 56 47.2 9 7.2 40.5 18.2 M8X30 42 FS-12P 3/4" 71 60 11 8.2 50.8 23.8 M10X35 FS-16P 1" 81 69.6 13.5 9 57.2 27.8 M12X45 FS-20P 1.1/4" 95 77.2 13.5 9.8 66.6 31.8 M12X45 FS-24P 1.1/2" 113 95 17.5 12 79.3 36.5 M16X55 FS-32P 2" 133 113.8 22 12 96.8 44.5 M20X70 PEHEL has been engaged in hydraulic components’ design and production for fifteen years and has passed ISO9001 Quality Certificate among the first. We have own import & export license.
Application: Automobile, engineering Machinery, Lathe, Machinery, Metallurgy, Petroleum, mine, construction, chemical industry, shipbuilding, spacecraft, military, Textile, Ocean, Recreation, Electronics and many other fields related with hydraulic and their delivery system of fluid and gas etc;1. Do you have products in stock?Yes, for most porducts, we have.2. Can you produce Non standard product?Yes, we can produce products as your requirements (according to your sample or drawing)3. What is your payment terms?Regularly,our payment term is : 30% deposit advance the producing, 70% balance before shiping.4. Can you accept LC payment?Yes, we can.5. Can you provide samples?Yes.
SAE Split Flange Clamp
PEHEL Hydraulic Model: FL-FS-P
QTY:
SAE Split Flange Clamp FS hydraulic fitting
- Carbon Steel FS hydraulic fittingSupply Ability: 20000 Piece/Pieces per Week FS hydraulic fittingPackaging & delivery: Packaging DetailsNylon plastic+Corrugated carton+Multiply plywood case Port Ningbo
