PART NO. FLANGE SIZE DIMENSIONS with bolt Mpa A B d H M N 3000PSI 4FL-08WP 1/2" 54 46 9 16 38.1 17.5 M8X30 34.5 4FL-12WP 3/4" 65 50 11 16 47.6 22.2 M10X35 4FL-16WP 1" 70 55 11 18 52.4 26.2 M10X35 4FL-20WP 1.1/4" 79 68 11 18 58.7 30.2 M10X40 27.6 4FL-24WP 1.1/2" 93 78 13.5 20 69.9 35.7 M12X45 M12X45 20.7 4FL-32WP 2" 102 90 13.5 20 77.8 42.9 4FL-40WP 2.1/2" 114 105 13.5 20 88.9 50.8 M12X45 17.2 4FL-48WP 3" 134 125 17.5 22 106.4 61.9 M16X50 13.8 4FL-56WP 3.1/2" 152 136 17.5 22 120.7 69.9 M16X50 3.4 4FL-64WP 4" 162 146 17.5 25 130.2 77.8 M16X50 4FL-80WP 5" 190 170 17.5 28 152.4 92.1 M16X50 6000PSI 4FS-08WP 1/2" 54 46 9 16 40.5 18.2 M8X30 41.4 4FS-12WP 3/4" 71 55 11 19 50.8 23.8 M10X35 4FS-16WP 1" 81 65 13 24 57.2 27.8 M12X45 4FS-20WP 1.1/4" 95 78 15 27 66.6 31.8 M14X45 4FS-24WP 1.1/2" 112 94 17 30 79.3 36.5 M16X50 4FS-32WP 2" 134 114 22 37 96.8 44.5 M20X65 Find the right product for your company. Our wide range of products consisting of over 8000 individual parts makes it possible to create customized solutions for your company. Our product portfolio includes SAE flanges (ISO 6162), SAE full flanges, screws,-in flanges external thread flanges, weld-in and weld-on flanges as well as flanges with butt-welded collars. These products can all be delivered in straight and 90° versions.
Click Contact Us to leave a message and get product details
Furthermore we can deliver closing flanges, connecting flanges, flanges with measurement connections, T-connectors, reducing flanges, raised-edge flanges and SAE blocks. These as well as connections for gear pumps and square-head flange connections (ISO 6164) are as straight and 90° versions and Cetop (standard) versions.
SAE Closed Flange
PEHEL Hydraulic Model: 4FL-WP
QTY:
