90 JIC Male 74 Cone / SAE Flange 6000PSI

90 JIC Male 74 Cone / SAE Flange 6000PSI

PEHEL Hydraulic Model: 1JFS9

QTY:

90 Degree Elbow JIC Male 74 Degree Cone Flared Tube Fitting, Hydraulic Fitting, Adapter

  • 1JFS9 JIC ELBOW MALE HEAVY SERIES FLANGE HYDRAULIC FLANGES ISO 6162-1 - Buy sae hydraulic heavy flange, carbon steel pipe fittings, hydraulic hose connections Product on PEHEL Hydraulic

  • 90 JIC Male 74 Cone / SAE Flange 6000PSI Specification
  • You May Also Like
  • PART NO. THREAD FLANGE SIZE O RING DIMENSIONS
    E A B b D1 D2 S1
    1JFS9-08 3/4"X16 1/2" 18.64X3.53 38 38 7.9 31.7 23.9 24
    1JFS9-10-08 7/8"X14 1/2" 18.64X3.53 38 38 7.9 31.7 23.9 24
    1JFS9-10-12 7/8"X14 3/4" 24.99X3.53 45 42 8.9 41.3 31.7 30
    1JFS9-12 1.1/16"X12 3/4" 24.99X3.53 44.2 54.1 8.76 41.3 32 27
    1JFS9-12-16 1.1/16"X12 1" 32.92X3.53 50 45 9.6 47.6 38 36
    1JFS9-16 1.5/16"X12 1" 32.92X3.53 49 60.2 9.53 47.6 38 33
    1JFS9-16-12 1.5/16"X12 3/4" 24.99X3.53 45 42 8.9 41.3 31.7 30
    1JFS9-16-20 1.5/16"X12 1.1/4" 37.69X3.53 59 50 10.4 54 43.6 41
    1JFS9-20 1.5/8"X12 1.1/4" 37.69X3.53 55.5 66.5 10.29 54 44 41
    1JFS9-20-16 1.5/8"X12 1" 32.92X3.53 50 45 9.6 47.6 38 36
    1JFS9-20-24 1.5/8"X12 1.1/2" 47.22X3.53 76 76 12.7 63.5 50.8 50
    1JFS9-24 1.7/8"X12 1.1/2" 47.22X3.53 62.5 79.3 12.57 63.5 51 48
    1JFS9-24-20 1.7/8"X12 1.1/4" 37.69X3.53 68 68 10.4 54 43.6 41
    Nut and sleeve should be ordered separately.The nut NB200 and sleeve NB500 is suitable for metric tube,the nut NB200 and sleeve NB300 is suitable for inch tube.
