Metric Size Inch Size SAE Dash Size I.D O.D. Allowed Tolerance Max W.P Min B.P Min B.R W.T Standard Standard mm Inches Dash mm mm mm Mpa Bar Psi Mpa mm g/m *3.5 1/8 02 3.5 7.1 ±0.10 35 350 5070 140.0 30 35 *5 3/16 03 4.8 10.3 ±0.10 35 350 5070 140.0 35 65 6.3 1/4 04 6.3 12.3 ±0.10 38 375 5440 150.0 40 90 8 5/16 05 7.9 14.3 ±0.10 33 325 4710 130.0 45 115 10 3/8 06 9.5 16.7 ±0.15 28 280 4060 112.0 60 145 12.5 1/2 08 12.7 19.8 ±0.15 25 250 3620 100.0 80 205 16 5/8 10 15.9 24.5 ±0.15 23 225 3260 90.0 120 290 19 3/4 12 18.9 28.0 ±0.15 18 175 2540 70.0 140 345 25 1/1 16 25.4 34.0 ±0.15 15 150 2170 60.0 160 450
Aramid Fiber Braid Resin Hose
PEHEL Hydraulic Model: SAE 100R8 / EN855 R8
QTY:
