Metric Size Inch Size SAE Dash Size I.D O.D. Allowed Tolerance Max W.P Min B.P (Mpa) Min B.R (mm) W.T (g/m) Standard Standard(mm) One Layer Two Layer mm Inches Dash mm One Layer Two Layer mm Bar Psi Bar Psi One Layer Two Layer One Layer Two Layer One Layer Two Layer 5 3/16 03 4.8 10.3 10.8 ±0.10 210 3045 250 3620 84.0 100.0 35 55 65 70 6.3 1/4 04 6.3 12.7 13.3 ±0.10 200 2900 275 3980 80.0 110.0 50 75 80 125 8 5/16 05 7.9 14.3 15.0 ±0.10 190 2755 260 3770 76.0 105.0 50 85 125 150 10 3/8 06 9.5 15.9 18.0 ±0.10 175 2540 250 3620 70.0 100.0 80 100 140 210 12.5 1/2 08 12.7 19.8 21.6 ±0.15 140 2030 210 3040 56.0 84.0 100 140 200 260 16 5/8 10 15.9 23.3 23.6 ±0.15 130 1885 160 2320 52.0 64.0 160 165 260 295 19 3/4 12 18.9 26.5 26.4 ±0.15 90 1305 140 2030 36.0 56.0 180 195 320 315 25 1/1 16 25.4 34.0 34.0 ±0.20 70 1015 105 1520 28.0 42.0 250 256 400 450
Fiber Braid (nonmetallic) Resin Hose
PEHEL Hydraulic Model: SAE 100R7 / EN855 R7(FIBER BRAID)
QTY:
