heavy tube clamp; DIN3015 standard
Order code
PTHPG----Heavy series,polyproylene inside grooved
PTHPS----Heavy series,polyproylene inside smoothPTHNG----Heavy series,polyamide 6, inside grooved
PTHNS----Heavy series,polyamide 6, inside smooth
(As required,exchange standard abbrevietion THPG in column of "order code")
.jpg)
Clamp size mm O.D. inch I.D. inch O.D. 2 clamp halves THPG 4 clamp halves THPGD Order code Size Order code Size b c d e f b c d e f 1 6
8
10
12
12.7
13.5
14
15
16
17.2
18G1/8
G1/4
G3/8
5/16
5/8PTHPG-106
PTHPG-108
PTHPG-110
PTHPG-112
PTHPG-112.7
PTHPG-113.5
PTHPG-114
PTHPG-115
PTHPG-116
PTHPG-117.2
PTHPG-11855 32 33 16 30 PTHPGD-106
PTHPGD-108
PTHPGD-110
PTHPGD-112
PTHPGD-112.7
PTHPGD-113.5
PTHPGD-114
PTHPGD-115
PTHPGD-116
PTHPGD-117.2
PTHPGD-11855 32 33 16 60 2 18
19
20
21.3
22
23
25
26.9
28
30G1/2
G3/43/4
1PTHPG-218
PTHPG-219
PTHPG-220
PTHPG-221.3
PTHPG-222
PTHPG-223
PTHPG-225
PTHPG-226.9
PTHPG-228
PTHPG-23070 48 45 24 30 PTHPGD-218
PTHPGD-219
PTHPGD-220
PTHPGD-221.3
PTHPGD-222
PTHPGD-223
PTHPGD-225
PTHPGD-226.9
PTHPGD-228
PTHPGD-230
70 48 45 24 603 30
32
33.7
35
38
40
42G1
G11/4
11/4
11/2PTHPG-330
PTHPG-332
PTHPG-333.7
PTHPG-335
PTHPG-338
PTHPG-340
PTHPG-34285 60 60 30 30 PTHPGD-330
PTHPGD-332
PTHPGD-333.7
PTHPGD-335
PTHPGD-338
PTHPGD-340
PTHPGD-34285 60 60 30 60 4 38
40
42
45
48.3
50
51
52
55
57
60.3
63
65
70G11/4
G11/2
G2
11/2
2
21/4
21/2
PTHPG-438
PTHPG-440
PTHPG-442
PTHPG-445
PTHPG-448.3
PTHPG-450
PTHPG-451
PTHPG-452
PTHPG-455
PTHPG-457
PTHPG-460.3
PTHPG-463
PTHPG-465
PTHPG-470115 90 90 45 45 PTHPGD-438
PTHPGD-440
PTHPGD-442
PTHPGD-445
PTHPGD-448.3
PTHPGD-450
PTHPGD-451
PTHPGD-452
PTHPGD-455
PTHPGD-457
PTHPGD-460.3
PTHPGD-463
PTHPGD-465
PTHPGD-470
115 90 90 45 905 70
73
75
76.1
80
82.5
88.9
90G21/2
G3
3
31/4
31/2
PTHPG-570
PTHPG-573
PTHPG-575
PTHPG-576.1
PTHPG-580
PTHPG-582.5
PTHPG-588.9
PTHPG-590152 120 122 60 60 PTHPGD-570
PTHPGD-573
PTHPGD-575
PTHPGD-576.1
PTHPGD-580
PTHPGD-582.5
PTHPGD-588.9
PTHPGD-590152 120 122 60 120 6 90
97
100
101.6
108
114.3
127G31/2
G4
4
41/4
41/2
PTHPG-690
PTHPG-697
PTHPG-6100
PTHPG-6101.6
PTHPG-6108
PTHPG-6114.3
PTHPG-6127205 170 168 85 80 PTHPGD-690
PTHPGD-697
PTHPGD-6100
PTHPGD-6101.6
PTHPGD-6108
PTHPGD-6114.3
PTHPGD-6127205 170 168 85 160 7 127
133
140
150
152.4
159
165.1
168.3G5
G51/2G6
5
51/4
51/2
6
61/4
61/2
65/8PTHPG-7127
PTHPG-7133
PTHPG-7140
PTHPG-7150
PTHPG-7152.4
PTHPG-7159
PTHPG-7165.1
PTHPG-7168.3250 200 205 100 90 PTHPGD-7127
PTHPGD-7133
PTHPGD-7140
PTHPGD-7150
PTHPGD-7152.4
PTHPGD-7159
PTHPGD-7165.1
PTHPGD-7168.3250 200 205 100 180 8 168.3
177.8
193.7
203
219.1
220G8
65/8
7
75/8
85/8PTHPG-8168.3
PTHPG-8177.8
PTHPG-8193.7
PTHPG-8203
PTHPG-8219.1
PTHPG-8220320 270 265 135 120 PTHPGD-8168.3
PTHPGD-8177.8
PTHPGD-8193.7
PTHPGD-8203
PTHPGD-8219.1
PTHPGD-8220320 270 265 135 240
Heavy Tube Clamp DIN3015
PEHEL Hydraulic Model: Heavy Tube Clamp PTHPG-PTHPGD
QTY:
- heavy tube clamp; DIN3015 standard, from small to big size, 2 welding plate model for choice
