THREAD CAPTIVE DIMENSIONS PART NO. E F E A L S1 5B-02-04WD G1/8"X28 G1/4"X19 WD-B02 8 30.5 19 5B-02-06WD G1/8"X28 G3/8"X19 WD-B02 8 32.5 22 5B-04-02WD G1/4"X19 G1/8"X28 WD-B04 12 31.5 19 5B-04-06WD G1/4"X19 G3/8"X19 WD-B04 12 37 22 5B-04-08WD G1/4"X19 G1/2"X14 WD-B04 12 43 27 5B-06-02WD G3/8"X19 G1/8"X28 WD-B06 12 30.5 22 5B-06-04WD G3/8"X19 G1/4"X19 WD-B06 12 37.5 22 5B-06-08WD G3/8"X19 G1/2"X14 WD-B06 12 43.5 27 5B-08-04WD G1/2"X14 G1/4"X19 WD-B08 14 38 27 5B-08-06WD G1/2"X14 G3/8"X19 WD-B08 14 41 27 5B-08-12WD G1/2"X14 G3/4"X14 WD-B08 14 46 36 5B-12-08WD G3/4"X14 G1/2"X14 WD-B12 16 47.5 32 5B-12-16WD G3/4"X14 G1"X11 WD-B12 16 53.5 41 5B-12-20WD G3/4"X14 G1.1/4"X11 WD-B12 16 54.5 50 5B-16-12WD G1"X11 G3/4"X14 WD-B16 18 50.5 41 5B-16-20WD G1"X11 G1.1/4"X11 WD-B16 18 56.5 50 5B-20-16WD G1.1/4"X11 G1"X11 WD-B20 20 57.5 50 5B-20-24WD G1.1/4"X11 G1.1/2"X11 WD-B20 20 59.5 55 5B-20-32WD G1.1/4"X11 G2"X11 WD-B20 20 64 70 5B-24-16WD G1.1/2"X11 G1"X11 WD-B24 22 59.5 55 5B-24-20WD G1.1/2"X11 G1.1/4"X11 WD-B24 22 60 55 5B-24-32WD G1.1/2"X11 G2"X11 WD-B24 22 66 70
BSP MALE CAPTIVE SEAL/ BSP FEMALE
PEHEL Hydraulic Model: P5B-WD
QTY:
