PART NO.
THREAD DIMENSIONS E F A B S L P1JM-04-12WD 7/16"X20 M12X1.5 14 12 17 34 P1JM-05-14WD 1/2"X20 M14X1.5 14 12 19 34 P1JM-06-14WD 9/16"X18 M14X1.5 14.1 12 19 34 P1JM-06-18WD 9/16"X18 M18X1.5 14.1 12 24 36.5 P1JM-06-20WD 9/16"X18 M20X1.5 14.1 14 27 40.5 P1JM-08-16WD 3/4"X16 M16X1.5 16.7 12 22 38.5 P1JM-08-18WD 3/4"X16 M18X1.5 16.7 12 24 39 P1JM-08-20WD 3/4"X16 M20X1.5 16.7 14 27 43 P1JM-08-22WD 3/4"X16 M22X1.5 16.7 14 27 43.5 P1JM-10-20WD 7/8" X14 M20X1.5 19.3 14 27 45.5 P1JM-10-22WD 7/8" X14 M22X1.5 19.3 14 27 46 P1JM-12-18WD 1.1/16" X12 M18X1.5 21.9 12 30 46.5
USA JIC Thread 74 Conical Surface Sealing Transition Joint
PEHEL Hydraulic Model: P1JM-WD
QTY:
