Home / Hose Fitting Metric Standard / 24° Cone O-Ring Seal L.T. / Metric Male 24°cone Seat L.T.
Metric Male 24°cone Seat L.T.

Metric Male 24°cone Seat L.T.

PEHEL Hydraulic Model: P10411

QTY:

Metric Male 24°cone Seat L.T. Cheap Hose Hydraulic adapter hydraulic fitting coupling 10411

  • Metric Male 24°cone Seat L.T. Specification
  • You May Also Like
  • PART NO. THREAD E HOSE BORE TUBE O.D. DIMENSIONS
    DN DASH C S1 Per hundred weight
    		 Weight per case
    P10411-12-04 M12x1.5 6 4 6 10.7 14 1.6 500
    P10411-12-04A M12X1.25 6 4 6 10.7 14 500
    P10411-14-04 M14x1.5 6 4 8 13 17 2 500
    P10411-14-05 M14x1.5 8 5 8 13 17 2.5 300
    P10411-16-04 M16x1.5 6 4 10 13.5 17 2.9 250
    P10411-16-05 M16x1.5 8 5 10 13.5 17 3 250
    P10411-16-06 M16x1.5 10 6 10 13.5 17 3.2 250
    P10411-18-05 M18X1.5 8 5 12 13.5 19 3.9 200
    P10411-18-06 M18X1.5 10 6 12 13.5 19 4.1 200
    P10411-20-04 M20X1.5 6 4 14 13.5 22 150
    P10411-20-08 M20X1.5 12 8 14 13.5 22 150
    P10411-22-06 M22X1.5 10 6 15 13.5 24 6.2 150
    P10411-22-08 M22X1.5 12 8 15 13.5 24 6.7 100
    P10411-24-08 M24X1.5 12 8 18 13.5 27 100
    P10411-26-08 M26X1.5 12 8 18 14 27 9 170
    P10411-26-10 M26X1.5 16 10 18 14 27 9.2 170
    P10411-27-08 M27X1.5 12 8 18 14 30 170
    P10411-27-10 M27X1.5 16 10 18 14 30 11 150
    P10411-27-12 M27X1.5 20 12 18 14 30 12 150
    P10411-30-08 M30X2 12 8 22 18 32 150
    P10411-30-10 M30X2 16 10 22 18 32 12 150
    P10411-30-12 M30X2 20 12 22 18 32 15 125
    P10411-36-16 M36X2 25 16 28 18 38 26.4 70
    P10411-45-20 M45X2 32 20 35 19 46 39.8 40
    P10411-52-24 M52X2 40 24 42 19 55 64.4 30
