Home / Hose Fitting Metric Standard / 24° Cone O-Ring Seal H.T. / Metric Female 24º Cone O-ring H.T.

Metric Female 24º Cone O-ring H.T.

PEHEL Hydraulic Model: P20512-T

QTY:

20512/20512-t Metric Female 24° Cone O-ring H.t. Hydraulik Hose Fitting Pipe Fitting Coupling

  • You May Also Like

  • PART NO. THREAD E HOSE BORE TUBE O.D. DIMENSIONS
    DN DASH C S2
    P20512-18-04T M18X1.5 6 04 10 2 22
    -20-05 M20X1.5 8 05 12 2.5 24
    -22-06 M22X1.5 10 06 14 2.5 27
    -24-08 M24X1.5 12 08 16 3 30
    -30-10 M30X2 16 10 20 3 36
    -36-12 M36X2 20 12 25 3 41
    -42-16 M40X2 25 16 30 5 50
    -52-10 M52X2 32 20 38 6.5 60
